Bel-Air
Underlayments

High Density Pad





Category:
  • Moisture Cured Urethane Technology
  • Permanent Bond
  • Excellent Ridge Retention
  • Easy to Trowel
Order a Sample

Description

Features:

Product Information:

Thickness: 1.5mm.
Width: 45” (3.75 Ft.)
Length: 320” (27 Ft.)
Weight: 10 Lbs.
Density: 150KG/m3

Roll Diameter: 7”Ft.2 Per Roll: 100 Ft.2
Rolls Per Pallet: 50 Rolls

Technical Information:

IIC – Impact Insulation Class: 73 dB
STC – Sound Transmission Class: 72 dB
Thermal Conductivity: 0.039 W/(m•K)
Thermal Resistance: 0.084 (m2•K)/W

AntimicrobialTreatment: ULTRA-FRESH
Thermal Resistance: R-Value .15
Compression Resistance: 42.21 psi
Compression Standard: 3%


Spec. Sheet

Spec. Sheet

Product Information

  • BrandBel-Air
  • CollectionUnderlayments
