Bel-Air
Underlayments

Blue Foam





Category:
  • Moisture Cured Urethane Technology
  • Permanent Bond
  • Excellent Ridge Retention
  • Easy to Trowel
Order a Sample

Description

Features:

Product Information:

Thickness: 2.0mm.
Width: 45” (3.75 Ft.)
Length: 636” (53.3 Ft.)
Weight: 2 Lbs.
Density: 24KG/m3
Roll Diameter: 8”Ft.2 Per Roll: 200 Ft.2
Rolls Per Pallet: 50 Rolls

Technical Information:

STC – Sound Transmission Class: 54 dB
IIC – Impact Insulation Class: 51 dB

Classification Standard

STC Classification: ASTM E90-04, 54dB
IIC Classification: ASTM E492-04, 51dB
Thermal Conductivity: 0.20 BTU/Hr.Sq.In
Fire Resistance: UL 94 HFI, F.A.R. 25.83
Water Absorption: 0.003 Lbs Per Cubic Feet


Spec. Sheet

Spec. Sheet

Product Information

  • BrandBel-Air
  • CollectionUnderlayments
